MoU templates

MoU templates#

What are MoU templates useful for?#

The integration of Mobile Network Operator (MNO) data into national data systems is a complex process, which first requires securing data access and agreeing on overarching principles of collaboration between key stakeholders such as MNOs, National Statistical Offices (NSO), Regulatory Authorities (RA), Data Protection Authorities (DPA), and others. This critical milestone is usually achieved through the signing of a Memorandum of Understanding (MoU).

Although the scope and content of an MoU may vary across contexts, it is desirable that it covers at least the following 5 key pillars:

🤝Roles and Responsibilities: which stakeholder is responsible for what?
🔄Data Sharing Protocols: what data is shared, and how?
🔑Data Access Protocols: who can access the data, and how?
✅Permitted Data Use and Dissemination: what is the intended data use, what indicators are permitted and how are results disseminated?
🛡️Data Safeguards: how are data security and privacy ensured throughout the data pipeline?

To support World Bank task teams and others in formalizing data access modalities, MoU templates were produced under the GDF-MPD project and cover the essential aspects described above. Three templates were developed, coinciding with three distinct configurations of data sharing modalities (also called “data pipeline models”). The templates are available in English and French and can be downloaded at the bottom of this page. Details on the characteristics of each of the three models are provided below.

Warning

MoU templates accomodate archetypal data pipeline architectures but are only intended to provide a general structure with key content and were not designed as one-size-fits-all tools. They should always be adjusted to country specific needs and context. Particular attention should be paid to aligning the MoU with the relevant regulatory framework.

The three main data pipeline models#

Definition of three data tiers#

🔴Tier I “nano” data: raw data records of the form <user ID , timestamp , antenna ID>.
🔴Tier I “micro” data: device-level summary measures of Tier I “nano” data for a specified time period.
🟠Tier II data: summary measure of Tier I data (from a given MNO) aggregated at the level of spatial units for a specified time period.
🟢Tier III data: statistics on a well-defined target population, derived from the combination of Tier II data (possibly from multiple MNOs) and non-MNO data (e.g. census, household surveys).

MNO-centric model (model A)#

Roles assignment in MNO-centric Model

Role	Actor
Data Custodian - Stores & manages data	MNO
Data Controller - Decides data usage	NSO / Gov Agencies
Data Processor - Develops methods & scripts	MNO / NSO
Data Processor - Runs scripts	MNO

Schematic figure showing the architecture of data pipeline model A — Fig. 1 **Schematic illustration of the architecture of data pipeline model A.**#

Regulator-centric model (model B)#

Roles assignment in Regulator-centric Model

Role	Actor
Data Custodian - Stores & manages data	Regulator
Data Controller - Decides data usage	NSO / Gov Agencies
Data Processor - Develops methods & scripts	NSO
Data Processor - Runs scripts	NSO

Schematic figure showing the architecture of data pipeline model B — Fig. 2 **Schematic illustration of the architecture of data pipeline model B.**#

Hybrid model (model AB)#

Roles assignment in Hybrid Model

Role	Actor
Data Custodian - Stores & manages data	MNO
Data Controller - Decides data usage	NSO / Gov Agencies
Data Processor - Develops methods & scripts	NSO
Data Processor - Runs scripts	NSO

Schematic figure showing the architecture of data pipeline model AB — Fig. 3 **Schematic illustration of the architecture of data pipeline model AB.**#

Download MoU templates#

MoU template - model A (English)

MoU template - model A (Fench)(available soon)

MoU template - model B (English)

MoU template - model B (French)

MoU template - model AB (English)

MoU template - model AB (French)
